(1) 10/100/1000 Ethernet Port, (1) 10/100 Ethernet Port, 1.2+ Gbps, 128-bit AES, airOS F, SISO/MIMO

Key Features

• Full duplex Point-to-Point radio
• 11 GHz frequency operation
• Up to 1.2+ Gbps throughput
• Proprietary INVICTUS™ processor
• Integrates with airFiber® 11 GHz antennas
• Utilizes distinct Rx and Tx frequencies
• Accepts PoE or DC power
• Secure 128-bit AES encryption

Description

Breaking free from the congested 5 GHz band, airFiber® 11 is the first modular airFiber radio system purpose-built for the 11 GHz licensed frequency market. Housed in a compact, highly efficient form factor, airFiber 11 delivers amazing wireless gigabit+ performance, low latency, and long range, making it ideal for carrier backhaul, building-to-building enterprise use, or public safety applications.

Specifications

Data transmission
Maximum data transfer rate	1000 Mbit/s
Wireless LAN features
Wi-Fi	Yes
Wi-Fi band	Single-band (5 GHz)
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ports & interfaces
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	2
Security
Security algorithms	128-bit AES
Features
Product type	Network bridge
Product colour	White
Processor model	INVICTUS 2 IC
LED indicators	Yes
Power
Power source type	DC, PoE
Operational conditions
Operating temperature (T-T)	-40 - 50 °C
Management features
LED indicators	Yes
Certificates
Certification	FCC Part 101, ETSI EN 302 217
Technical details
Product colour	White
Harmonized System (HS) code	85176990
Weight & dimensions
Weight	2.26 kg
Width	112 mm
Depth	86 mm
Height	327 mm
Processor
Processor model	INVICTUS 2 IC
Logistics data
Harmonized System (HS) code	85176990
