Intel Core i7-14700, 20C (8P + 12E)/28T, Max Turbo up to 5.4GHz, P-core 2.1/5.3GHz, E-core 1.5/4.2GHz, 33MB Intel Smart Cache, 1x 16GB UDIMM DDR5-4400, 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0, Intel UHD Graphics 770, Intel Wi-Fi 6E AX211 802.11ax 2x2 + BT5.3 vPro, Windows 11 Pro

Key Features

• Intel Core i7-14700, 20C (8P + 12E)/28T, Max Turbo up to 5.4GHz, P-core 2.1/5.3GHz, E-core 1.5/4.2GHz, 33MB Intel Smart Cache
• 1x 16GB UDIMM DDR5-4400
• 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0
• Intel UHD Graphics 770
• Windows 11 Pro

Reasons To Buy

Peak Processing Performance

No program is too intricate, and no file is too massive to hinder the Lenovo ThinkCentre M90s Gen 5 (Intel) small form factor (SFF) from operating at the speed of human imagination. With cutting-edge Intel vPro® Enterprise technology and Intel® Core™ processors, this desktop delivers real-world, top-notch performance for business needs.

Confidently Secured

Lenovo ThinkShield offers thorough security, combining hardware and software to protect your data. The discrete Trusted Platform Module (dTPM) chip encrypts passwords and data, while BIOS-based Smart USB Protection prevents unauthorized access through peripherals. Leveraging the Intel vPro® platform, this device enhances data and asset security.

Expandable Flexibility

The Smart Cable offers cutting-edge device collaboration through convenient USB-A and USB-C® connections, accommodating all your peripherals, including laptops and tablets. Seamlessly share device control, data, and screen projection between devices with this intelligent feature, supporting high-speed USB-C® data transfers.

Environmentally Aware

This small form factor PC was crafted with a strong emphasis on recycling. Our commitment to sustainability is evident in the integration of recycled post-consumer content (PCC) into various components. The packaging is thoughtfully designed using a combination of recycled and sustainably sourced materials.

Description

- Transform your workflow with integrated AI for advanced data analysis
- Crafted for increased reliability now and in the future
- Elevated creative potential with the aid of enhanced graphics
- Robustly secure & reliable, certified energy-efficient

Specifications

Processor
Processor generation	Intel® Core™ i7 (14th gen)
Processor cache type	Smart Cache
Processor cache	33 MB
Processor frequency	2.1 GHz
Processor model	i7-14700
Processor manufacturer	Intel
Processor boost frequency	5.3 GHz
Processor threads	28
Processor cores	20
Processor family	Intel® Core™ i7
Memory
Memory layout (slots x size)	1 x 16 GB
Internal memory	16 GB
Maximum internal memory	128 GB
Memory slots	4x DIMM
Internal memory type	DDR5-SDRAM
Memory clock speed	4400 MHz
Memory channels	Dual-channel
Storage
Storage media	SSD
Optical drive type	DVD±RW
SSD interface	PCI Express 4.0
SSD capacity	512 GB
Number of SSDs installed	1
Card reader integrated	Yes
Total storage capacity	512 GB
SSD form factor	M.2
Total SSDs capacity	512 GB
NVMe	Yes
M.2 SSD size	2280 (22 x 80 mm)
Self-Encrypting Drive (SED)	Yes
Graphics
Discrete graphics card	No
On-board graphics card family	Intel® UHD Graphics
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card model	Intel UHD Graphics 770
On-board GPU manufacturer	Intel
Performance
Product type	PC
Trusted Platform Module (TPM)	Yes
Motherboard chipset	Intel Q670
Trusted Platform Module (TPM) version	2.0
Fingerprint reader	No
Audio chip	Realtek ALC897Q-CG
Number of speakers	1
Audio system	High Definition Audio
Optical drive
Optical drive type	DVD±RW
Network
Ethernet LAN	Yes
Wi-Fi	Yes
Bluetooth	Yes
Bluetooth version	5.3
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Ethernet LAN data rates	100,1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
WLAN controller model	Intel Wi-Fi 6E AX211
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Antenna type	2x2
WLAN controller manufacturer	Intel
Ports & interfaces
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Thunderbolt 3 ports quantity	0
HDMI version	2.1
USB 2.0 ports quantity	0
Microphone in	Yes
Line-out	Yes
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
DisplayPorts quantity	2
Power
Power supply	310 W
Technical details
Cable lock slot type	Kensington
Product type	PC
Trusted Platform Module (TPM)	Yes
Product colour	Black
Chassis type	SFF
Audio system	High Definition Audio
Cable lock slot	Yes
Motherboard chipset	Intel Q670
Design
Volume	8.2 L
Cable lock slot type	Kensington
Product colour	Black
Chassis type	SFF
Cable lock slot	Yes
Software
Operating system language	English
Operating system installed	Windows 11 Pro
Processor special features
Intel® Smart Cache	Yes
Audio
Audio chip	Realtek ALC897Q-CG
Number of speakers	1
Audio system	High Definition Audio
Weight & dimensions
Volume	8.2 L
Width	92.5 mm
Depth	297.7 mm
Height	339.5 mm
Weight	5.3 kg
Packaging content
Mouse included	Yes
Keyboard included	Yes
Mouse connectivity	Wired
Keyboard connectivity	Wired
Certificates
Certification	TCO,RoHS,ErP,GREENGUARD
Keyboard
Keyboard connectivity	Wired
Other features
Number of speakers	1
Trusted Platform Module (TPM)	Yes
On-board graphics card	Yes
Processor manufacturer	Intel
Ethernet interface type	Gigabit Ethernet
