Intel Core i5-14500, 14C (6P + 8E)/20T, P-core 2.6/5.0GHz, E-core 1.9/3.7GHz, 24MB Intel Smart Cache, 1x 16GB SODIMM DDR5-4800, 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0, 23.8" FHD (1920x1080) IPS 250nits 60Hz 99% sRGB hardware low blue light flicker free eyesafe non-touch, Intel UHD Graphics 770, Intel Wi-Fi 6E AX211 802.11ax 2x2 + BT5.3 vPro, Windows 11 Pro

Key Features

• Intel Core i5-14500, 14C (6P + 8E)/20T, P-core 2.6/5.0GHz, E-core 1.9/3.7GHz, 24MB Intel Smart Cache
• 23.8" FHD (1920x1080) IPS 250nits 60Hz 99% sRGB hardware low blue light flicker free eyesafe non-touch
• 1x 16GB SODIMM DDR5-4800
• 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0
• Intel UHD Graphics 770
• Windows 11 Pro

Reasons To Buy

Designed to brighten up any workspace

With its sleek design, the Lenovo ThinkCentre M90a Gen 5 all-in-one is a PC powerhouse. It runs on up to the Intel vPro® platform with 14th Gen Intel® Core™ processing muscle and boasts a stunning FHD display, with or without touchscreen. Plus, optional discrete graphics are ideal for video-editing or design work. Mounted on a choice of stands, including one that’s full function with adjustable tilt, lift, pivot, and swivel. And there’s even a docking space for your phone and keyboard to keep your workspace clutter-free.

A smarter way to work, by far

Thanks to our Intelligent Cooling Engine (ICE) 6.0, the ThinkCentre M90a Gen 5 all-in-one offers various power modes to meet your various computing needs. Choose a 15% power boost experience, a super quiet mode that cuts system noise by up to three decibels, or opt for maximum cooling. This cutting-edge PC also features optional smart human presence detection, enhancing both security and energy efficiency by recognizing when you're away from your machine.

Protecting your data, ideas, & more

Experience unparalleled peace of mind with ThinkShield, comprehensive security that comes with every ThinkCentre. The ThinkCentre M90a Gen 5 all-in-one PC leverages up to Intel vPro® for robust, hardware-enhanced device protection. Additional security measures include BIOS-based Smart USB Protection, and an optional physical shutter you can use to open and close the webcam, further safeguarding your privacy.

Because things happen

In addition to our stringent internal testing, the ThinkCentre M90a Gen 5 all-in-one PC has been evaluated against US Department of Defense's MIL-STD 810H standards and undergone more than 200 quality checks to confirm its ability to withstand extreme scenarios. These tests encompass a wide range of challenging factors, from the icy expanses of the Arctic tundra to dust-laden desert winds, including assessments for temperature, pressure, humidity, vibration, and beyond.

Built with the planet in mind

By 2025, Lenovo is committed to obtaining 90% of our global operations electricity from renewable sources, removing one-million tons of greenhouse gas emissions from our supply chain. It’s why this all-in-one PC, for instance, meets global standards for energy-efficiency and health & safety. And why it comes with 90% sustainable packaging and comprises recycled materials.Learn more about our environmental, social, and governance approach.

Description

- Stylish, sleek 23.8″ all-in-one PC for business
- Powered by up to Intel vPro® with 14th Gen Intel® Core™ processor
- Superb hi-res display with rich, lifelike colours
- Robust security features, including AI human presence detection
- Certified energy efficient, convenient phone & keyboard dock

Specifications

Display
HD type	Full HD
Colour gamut	99%
Panel type	IPS
Display diagonal	60.5 cm (23.8")
Display resolution	1920 x 1080 pixels
Touchscreen	No
Display brightness	250 cd/m²
RGB colour space	sRGB
Native aspect ratio	16:9
Low Blue Light technology	Yes
Anti-glare screen	Yes
Processor
Processor cache type	Smart Cache
Processor frequency	2.6 GHz
Processor boost frequency	5 GHz
Processor family	Intel® Core™ i5
Processor model	i5-14500
Processor cores	14
Processor cache	24 MB
Motherboard chipset	Intel Q670
Processor manufacturer	Intel
Memory
Memory form factor	DIMM/SO-DIMM
Internal memory	16 GB
Memory layout (slots x size)	1 x 16 GB
Maximum internal memory	64 GB
Internal memory type	DDR5-SDRAM
Memory slots	2
Memory slots type	SO-DIMM
Memory clock speed	4800 MHz
Hard drive
Storage media	SSD
Total storage capacity	512 GB
Storage
Storage media	SSD
Total storage capacity	512 GB
Optical drive type	DVD±RW
Card reader integrated	Yes
SSD interface	PCI Express 4.0
SSD capacity	512 GB
Number of SSDs installed	1
SSD form factor	M.2
Total SSDs capacity	512 GB
NVMe	Yes
M.2 SSD size	2280 (22 x 80 mm)
Graphics
Discrete graphics card	No
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card model	Intel UHD Graphics 770
Audio
Number of speakers	2
Built-in speaker(s)	Yes
RMS rated power	6 W
Built-in microphone	Yes
Number of microphones	2
Camera
Built-in camera	Yes
Total megapixels	5 MP
Privacy camera	Yes
Privacy type	Privacy shutter
Infrared (IR) camera	Yes
Optical drive
Optical drive type	DVD±RW
Network
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi	Yes
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.3
WLAN controller model	Intel Wi-Fi 6E AX211
Antenna type	2x2
WLAN controller manufacturer	Intel
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Combo headphone/mic port	Yes
USB 2.0 ports quantity	0
HDMI ports quantity	1
DisplayPorts quantity	1
Ethernet LAN (RJ-45) ports	1
Technical details
Fingerprint reader	No
Product type	All-in-One PC
Product colour	Black
Security chip	Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
Sustainability certificates	ENERGY STAR, TCO, EPEAT Gold, ErP, GREENGUARD
Security
Cable lock slot type	Kensington
Trusted Platform Module (TPM)	Yes
Cable lock slot	Yes
Design
Cable lock slot type	Kensington
Product colour	Black
Cable lock slot	Yes
Performance
Product type	All-in-One PC
Motherboard chipset	Intel Q670
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Software
Operating system language	English
Operating system installed	Windows 11 Pro
Processor special features
Intel® Smart Cache	Yes
Power
AC adapter power	180 W
Multimedia
Built-in camera	Yes
Total megapixels	5 MP
Privacy camera	Yes
Privacy type	Privacy shutter
Infrared (IR) camera	Yes
Weight & dimensions
Width (with stand)	539.6 mm
Depth (with stand)	217.3 mm
Weight (with stand)	8.13 kg
Sustainability
Sustainability certificates	ENERGY STAR, TCO, EPEAT Gold, ErP, GREENGUARD
Packaging content
Mouse included	Yes
Keyboard included	Yes
Keyboard language	UK English
Mouse connectivity	Wired
Keyboard connectivity	Wired
Other features
Fingerprint reader	No
On-board graphics card	Yes
SSD interface	PCI Express 4.0
SSD capacity	512 GB
Processor manufacturer	Intel
Number of SSDs installed	1
Ethernet interface type	Gigabit Ethernet
Security chip	Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
Infrared (IR) camera	Yes
